VITO XM
VITO XM cleans the coolant lubricant and stores it in its 100 l (220lbs) tank. It provides an easy in our workplace. Like every VITO filter system the XM provides a microfiltration up to 5 µm (200µin). The optimal quality of your coolant lubricant is preserved. The unique design makes sure the XM provides highest safety at work, due to avoiding direct contact with the lubricant. After filtration the lubricant can easily be pumped back into the basin automatically.
Big Savings:
- less tool wear
- less personnel costs
- less transport costs
- less disposal costs
- fast amortisation
Constant Quality:
- ...of your coolant lubricant
- ...of your workpieces
Easy Handling:
- automatic filtration
- fast pressure filtration
- low cleaning effort
Specifications
| Filtration power | up to 30 l/min / 66 lbs/min |
| Filtration | up to 5 ųm / 200µin |
| Particle uptake | 10,7 l / 23.6 lbs |
| Pumping capacity | 35 l/min / 77lbs/min |
| Tank | 100 l / 220lbs |
| Weight | 65 kg / 143lbs |
| Temperature | max. 200°C / 392°F |
| Material | Edelstahl 1.4301 |
